Rectangular 30in x 40in Mirror Defogger
Part Number: FFM-3040
This support page provides publications, manuals, specifications, videos, support articles, and common support questions
This support page provides publications, manuals, specifications, videos, support articles, and common support questions
Common Support Questions (9)
Publications and Manuals (3)
Specifications (18)
Videos (1)
Articles (4)
Similar Items (8)
Create a new Support Request
Shop Now
Common Support Questions
Electric-resistance heating cables and systems have no polarity. This includes all current WarmlyYours heating elements.
Need more help? View support options
The defogging is concentrated in the area of the heating element, but may spread out as the mirror warms up over time. There are too many variable atmospheric conditions that make it impossible to quote a fixed distance of heat spread away from the element. That is why the defogger must be placed in the area of the mirror that requires defogging.
Need more help? View support options
As long as the wood is not glued or attached with any form of mastic to the defogger, yes.
Need more help? View support options
Nothing can be put on the back of the defogger.
Need more help? View support options
It is 1.18“ (1-⅜“ or 30.1mm) square and .21“ (¼“ or 5.4mm) thick.
Need more help? View support options
Note that it may never get all the way to that temperature because different mirrors and environments will affect the final result, thereby affecting the length of time it takes to achieve temperature.
Need more help? View support options
None - it is peel and stick (comes with an adhesive backing).
Need more help? View support options
The main electrical line feeding the Mirror Defogger must incorporate a GFCI for North America.
Need more help? View support options
Yes.
Need more help? View support options
Publications and Manuals
Specifications
Electrical
| Amps | 1.28 A |
| Ohms | 86 Ω |
| Voltage | 120 V |
| Watts | 141 W |
Warranty / Certifications
| Approvals | cULus listed |
| Warranty | 1-year warranty against defects in materials and workmanship |
Performance
| BTU Per Hour | 481 Btu |
Installation
| Backing | Self-adhesive backing allows direct application to the back of any wall-hung mirror in just minutes |
Product Dimensions
| Coverage | 8 ft² |
| Height | 40″ |
| Size (Overall) | 30" x 40" |
| Thickness | 0.5 mm |
| Weight | 0.4 lbs |
| Width | 2′ 6″ |
Heat Outputs
| Regulated Heat | 104 F / 40 C |
Identifiers
| SKU | FFM-3040 |
| UPC (GTIN-12) | 881308034801 |
Appearance
| Shape | Rectangular |
