Relay with built-in transformer 240V


Relay with built-in transformer 240V

Support Page

Floor Heating Home Automation Integration Kits Description

WarmlyYours makes it easy to connect your floor heating system to your home automation system or stand-alone thermostat with our 240 V Integration Kit. The kit includes an electric heating relay with a built-in 24V/1.2VA/Class 2 transformer. Operating at a resistive load of 22 amps at 240 V, with epoxy soundproofing to ensure quiet relay operation, this 240 V Integration Kit includes 3-wire, double-pole switching and a 12 AWG terminal wire. Its low current consumption means that a single thermostat can control multiple relays. The heating command indicator light provides for immediate verification of relay operation, and a terminal board connection allows for ease of installation. The Integration Kit is C-UL-US Listed for safety, and WarmlyYours backs it with a 3-year warranty against manufacturer defects.

Specifications

Electrical

Connection Double Pole, three wire
Connection Method Hardwired
Maximum Load (Resistive Only) 22 amps
Transformer Ratings 24 VAC / 1.2 VA / Class 2
Voltage 240 V

Controls

Control Signal 24VAC / 40mA / 1.2VA

Logistics

Country of Origin (COO) China

Identifiers

Ground Fault Protection (GFCI) No
SKU INTEGRATION-KIT-240V
UPC (GTIN-12) 881308047535

Product Dimensions

Length 0.1″
Width 0.1″

Warranty / Certifications

Warranty 3 years

Customer Questions & Answers

Floor Heating Home Automation Integration Kits has 19 Questions and Answers.

Don't see the answer you're looking for? Post your question

How do I work with my electrician to install WarmlyYours electric floor heating?

While WarmlyYours electric radiant floor heating systems are typically installed by your floor covering contractor, a licensed electrician is recommended for the final thermostat hook-up. With every quote, we provide an Installation Plan layout, together with an electrical plan that has all the info required for the electrician.

35 people found this helpful.  Did you find this helpful? Yes No

How do I know if I am installing my electric floor heating system properly?

Please keep in mind that you must check your electric floor heating system with a digital ohmmeter in conjunction with a Circuit Check™. Take an initial reading as soon as you take the product out of the box to verify that it is within -5% / +10% of the values stated on the product’s label. This will give you a basis of comparison for future readings. Take a second reading once you have positioned the system to match your custom installation plan. It is also advisable to take an additional reading in the middle of the tile installation, just to make sure that the Circuit Check™ is doing its job. Then, take a final reading when you are finished with the floor installation and are ready to hook up the thermostat.

The Circuit Check™ is a tool developed by WarmlyYours to give you peace of mind and ensure trouble-free installations. Simply hook up the cold leads to the tool while you position the system to match your custom installation plan.

The Circuit Check™ will continuously monitor the continuity of the circuit during the installation of your system and during the installation of your flooring. The Circuit Check™ beeps immediately when a short in the system is detected, alerting you to a potentially damaged cable in the area you are working, before you lay the tile over the electric floor heating system.
 The WarmlyYours technical support team is available 24/7 to provide assistance if the alarm sounds, or if you would have any questions during your installation.

12 people found this helpful.  Did you find this helpful? Yes No

Can I use electric floor heating as a primary heat source?

Yes, in most cases, an electric floor heating system can be effective as a primary heat source. However, our TempZone™ and Environ™ systems are most commonly used as a secondary heat source, providing floor-to-ceiling radiant heat to any room in your home where you desire more warmth and comfort.

If you are considering electric floor heating for an addition to your home, such as a sunroom where you have no other source of heat, WarmlyYours offers an innovative online tool which calculates approximate heat loss. This tool can help you to determine if a WarmlyYours’ electric radiant floor heating system will provide your desired comfort temperature throughout the year. You can access the Heat Loss Calculator or you can call us at (800) 875-5285 and a Customer Service Representative will make the calculation for you.

8 people found this helpful.  Did you find this helpful? Yes No

How can I make my basement warmer?

A floor heating system can work as a supplemental heating source and make the basement warmer. If more heat needs to be added to the room, you can experiment with setting the floor heating thermostat to higher temperatures.

6 people found this helpful.  Did you find this helpful? Yes No

What breaker and wire size do I need to use for a floor heating system?

The breaker and wire sizes are selected based on the total amperage of the WarmlyYours heating system connected to a single thermostat. This information is on the WarmlyYours heating system's installation plan, electrical plan, or UL label. Based on guidelines from the National Electrical Code: loads up to 16 Amps may utilize 12 gauge wire with a 20-Amp breaker, and loads up to 12 Amps - 14 gauge wire with a 15-Amp breaker. Local code and/or other factors may change these guidelines.

6 people found this helpful.  Did you find this helpful? Yes No

View all 19 Questions and Answers

Customer Reviews

Floor Heating Home Automation Integration Kits achieved an average rating of 5.0 stars with 1 reviews by our customers.

Have you used this product before? Leave a review

Great product and excellent customer services!

Ninfa L., Hewlett, NY on 04/26/2021

I enjoy dealing with Mary who helped me to choose the right product for the project I engaged her on. Excellent customer service and she went the extra mile to ensure I got all of what I needed to complete the project. Product perfect for my needs...

View all customer reviews
