Radiant heat travels through air, and typically heats up objects closer to the panel first and then the rest of the room later. Infrared heating from the panel can be easily detected from about 3-4 feet. Ideally, the radiant panel should be aimed onto the area with more use, since that will be the surface that will warm up first.
Need more help? View support options
If you have a room with "average" insulation levels, take the square footage and multiply it by 7 or 8 watts per square foot. That will provide a good estimate of the watts needed to heat that space.
Need more help? View support options
Radiant panels using infrared heating can get very hot on the surface (up to 248° F). For safety, it is recommended that your radiant panel be mounted out of the reach of children.
Need more help? View support options
We do not have a Radiant Panels Running Cost Calculator. However, this can be determined easily by taking the panel’s wattage, dividing it by 1000, and then multiplying the result by the local kW/hr cost – then take this hourly cost and multiple by 730 hours to get a monthly estimate.
Need more help? View support options
The startup heating time for this infrared heating system is approximately 5 to 10 minutes. However, your room will not feel warmer immediately because the cold objects in the room (furniture, walls, ceilings, floors, etc.) need to warm up first. Once these surfaces are heated via infrared heating, the warmth will spread throughout the room.
Need more help? View support options
You can connect your plug-in radiant panels to a line voltage automated or a manual switch, timer, plug-in thermostat, or wifi switch. You can also use one of the controls found on our web page; https://www.warmlyyours.com/en-US/radiant-panels/controls
Need more help? View support options
We recommend an open 1.4" (3.6cm) space around the edge of the LAVA radiant panel for air circulation and easier installation. UL requires that the On/Off switch must be operable and visible, and no flammable materials may be used around the LAVA radiant panel.
Need more help? View support options
No.
Need more help? View support options
Please see this article.
Need more help? View support options
Please abide by local electrical code guidelines. Lava radiant panels may not be installed in "wet locations" such as showers or saunas. The top, bottom, and sides must not be closer than 12 inches from any other object or surface in order to effectively radiate heat. The Lava radiant panels may not be placed behind doors. We do not recommend installing Lava radiant panels on ceilings.
Need more help? View support options
Amps | 2.08 A |
Connection Method | Hardwired |
Ohms | 57.69 Ω |
Thermal Power | 0.25 kW |
Voltage | 120 V |
Watts | 250 W |
BTU Per Hour | 853 Btu |
Maximum Surface Temperature | 203 °F |
Country of Origin (COO) | Austria |
Finish | Red |
Version | Lava® Glass Red - 25″ X 20″ |
Installed Depth | 2.5″ |
Length | 1′ 8″ |
Size (Overall) | 25" x 20" (250W, 2.1A) |
Weight | 17.6 lbs |
Width | 2′ 1″ |
Model | Glass |
SKU | IP-0250-LV-RED |
UPC (GTIN-12) | 881308021603 |
