Hardwired WiFi Switch - White with White Wallplate


Part Number: GK16-30090-0003
This support page provides publications, manuals, specifications, videos, support articles, and common support questions


question-mark
Common Support Questions (11)

publication
Publications and Manuals (10)

specifications
Specifications (19)

Videos (1)

Articles (3)

Similar Items (5)

Create a new Support Request

Shop Now

Common Support Questions


Yes, most of our wall-mounted towel warmers have a fixed power location in the lower right corner.  All of our heated towel racks are electric "dry" (liquid/oil-free) units and most can be installed "upside down". Doing so will result in the power location relocating from the lower right corner to the upper left corner.

Please see the installation video here:  https://www.warmlyyours.com/en-US/video-media/towel-warmer-install

Need more help? View support options

A WarmlyYours electric towel warmer can't be installed in a tub or shower enclosure. A WarmlyYours electric heated towel rack should be installed at least 24” away from a wet location like a shower, tub, etc. Always install a WarmlyYours electric towel warmer in compliance with all local building and electrical codes.

Need more help? View support options

Yes. WarmlyYours towel warmers are to be installed in accordance with the instructions in the manual and CEC, NEC, and local code guidelines relating to electrical fixtures in bathrooms. A towel warmer with a hardwired connection must be on a GFCI-protected circuit and be wired by a professional who is certified to do electrical wiring. Towel warmer models with plug-in connections should be used with a GFCI outlet.

Need more help? View support options

WarmlyYours towel warmers are all 120VAC units. Towel warmers are available in wattages from 35 watts all the way up to 250 watts. A single towel warmer would typically range from 1-2 amps based on the model. Wire size and breaker size need to be selected based on the total amperage of the towel warmer(s). For towel warmers installed in bathrooms, a GFCI breaker is required.

Need more help? View support options

Yes, regular (non-dimming) light switch can be used as an external switch to control a towel warmer in addition to a built-in switch on the towel warmer itself. A GFCI breaker powering the switch may be required by local Electrical Code.

Need more help? View support options

If the app has scheduled turning on/off the towel warmer, it will override the manual setting.

Need more help? View support options

Yes, when using our Hardwired WiFi Switch which works with Amazon's Alexa, Google Assistant, or the Nest Thermostat (no hub required).

    Need more help? View support options

    If you are able to connect the mobile device to the Decora Smart Wi-Fi device (Step 2), but are getting a message that the device is unable to enroll please follow these troubleshooting step:

    1. Factory Reset the Decora Smart Wi-Fi device by pressing and holding the top paddle for 15 seconds (until the LED begins to flash red and amber), then release the paddle. After a few seconds, the LED will flash green.
    2. Pay attention to the Status LED during the remainder of the enrollment process. When you get to the step where the device joins your Wi-Fi network (right after you select your Wi-Fi network and enter the password):
      What is the color and state on the LED?
      • If the LED is solid green (or turns completely off if the light it is controlling is on), then please follow the steps in the following article: Device Does not Connect to Cloud
      • If the LED flashes amber, please make sure that you are entering the correct password for the Wi-Fi network that you are connecting to. The password is case specific. You can press the eye icon to see the text to make sure you entered it correctly.
    3. If your router has 2.4GHz and 5GHz Wi-Fi signals on the same Network Name (SSID), try splitting these out into different Wi-Fi network names.
      • For example, if you router uses the same Network Name (SSID) for both the 2.4GHz and 5GHz band. The modification is to change the name of the 5GHz SSID, so that it has a different name from the name of the 2.4GHz SSID. The recommendation is to add the number 5 to then end of the existing name. For example, if the name of your SSID is Jones, then change the name of the 5GHz SSID to Jones5.
    4. Attempt to enroll the device again after following all of these steps to see if you are successful. If not, please contact our technical support team at dssupport@leviton.com. Please include the type model number of the Decora Smart device and the brand and model of your wireless router.
    5. For additional help, you can call our support department.

    Need more help? View support options

    If the WiFi switch is not functioning to the My Leviton app's schedule or settings, it is recommended to either update the firmware of the WiFi switch from the Leviton app or, reset the WiFi switch by turning it on/off at the circuit breaker controlling the switch.

    Need more help? View support options

    Before you begin, please verify that you are attempting to enroll a Decora Smart Wi-Fi device. The first 2 characters of a Decora Smart Wi-Fi device is DW (e.g. DW15S, DW6HD, DW15P, etc.). If the device begins with a DHor DZ (e.g. DH15S, DZ15S, etc.), it is not a Decora Smart Wi-Fi device and cannot be used with My Leviton.If you are having trouble connecting your Decora Smart Wi-Fi device to your Wi-Fi network, take note of where the failure is occurring during the process (as described below), and follow the troubleshooting procedures for that step in the process. Refer to this article for all of the steps in the process: Add a Decora Smart Wi-Fi Device to the My Leviton App

    Also, make sure that the mobile app that you are using is named My Leviton. Other Leviton mobile apps, such as Decora Smart Home or Decora Digital Dimmer & Timer cannot be used for Decora Smart Wi-Fi devices.

    Need more help? View support options

    In Step 2 of the process, where you attempt to connect directly to the Decora Smart Wi-Fi device that is listed in the Wi-Fi networks (it will be listed in the format of Leviton Device-xxxx), instead of connecting you receive a message stating it is "unable to connect" or simple never connects (e.g. no check mark next to the device).
    If the device connects and you see this screen, skip to Decora Smart Wi-Fi device will not connect to the Wi-Fi Network or Leviton Cloud.
    If the mobile device does not connect to the Decora Smart Wi-Fi device at this step, please follow these troubleshooting step:

    1. Make sure you have the latest version of the My Leviton App. To ensure that you are running the latest version of the app, check for a My Leviton app update on the Apple App store or Google Play store.
    2. If available, try using a different mobile phone or tablet running the My Leviton app. Follow Steps 1 and 2 and see if you are able to connect to the device. If you are able to connect, see if you can complete the process.
    3. Contact our technical support team at dssupport@leviton.com. Please include the type and model of mobile devices you are using and the model number of the Decora Smart device.

    Need more help? View support options


    Publications and Manuals



    Specifications


    Appearance

    Color White
    Mounting Method In-wall, single-gang box

    Electrical

    Connection Method Hardwired
    Maximum Load (Resistive Only) 15 A
    Voltage 120 V

    Logistics

    Country of Origin (COO) United States of America

    Product Dimensions

    Depth 1.77″
    Height 4.66″
    Wallplate Depth 0.218″
    Weight 0.85 lbs
    Width 2.922″

    Warranty / Certifications

    FCC ID 001-DW15S-1BZ
    Warranty 5-year limited warranty

    Identifiers

    SKU GK16-30090-0003
    UPC (GTIN-12) 881308058418

    Connectivity

    Voice Control Works with Amazon Alexa, Apple Home/Siri, and Google Assistant voice assistants (sold separately)
    Wi-Fi IEEE Standards 802.11 a/b/g/n
    Wi-Fi Radio Frequency Bands 2.4 GHz
    Works with Works with My Leviton, Amazon Alexa, Hey Google, Apple Home/Siri, Schlage, SmartThings, or IFTTT (no hub required)
