| Amps | 2 A |
| Battery | 5-year battery backup of clock and calendar |
| Circuits Required | 1 |
| Connection | 4 wires, double pole |
| Connection Method | Hardwired |
| Floor Load | 0.24 kW |
| Ground Fault Protection | GFCI, Class A, 5 mA |
| Ground Fault Protection (GFCI) | Class A, 5 mA |
| Maximum Current | 15 A |
| Maximum Load (Resistive Only) | 1800 W - 120 V, 15 A / 3600 W - 240 V, 15 A |
| Maximum Load (Resistive Only) | 15 A |
| Maximum Power | 1800 W @ 120 V, 3120 W @ 208 V, 3600 W @ 240 V |
| Ohms | 60 Ω |
| Ohms Per Ft | 15 Ohm/ft |
| Supply | 120 VAC - 50/60Hz, 240 VAC - 50/60Hz |
| Thermal Power | 0.24 kW |
| Voltage | 120 V |
| Watts | 240 W |
| Watts Per Sq. Ft. | 15 Watts Per Sq. Ft. |
| Approvals | cULus listed |
| Ingress Protection (IPxx) Rating | IP20 |
| Proposition 65 Compliant | Yes |
| Warranty | 10 Year Warranty under Laminate & Floating Hardwood, 5 Year under Carpet (US Only) |
| Wet Location Listed | US, Canada |
| BTU Per Hour | 819 Btu |
| Drain Assembly Pressure Rating | 780 psi |
| Membrane Permeability | 0.07 perm |
| Cold Lead Length | 22′ |
| Coverage | 16 ft² |
| Depth | 2″ |
| Drain Hole Diameter | 5″ |
| Grate Size | 3.75” x 3.75” |
| Heating Element Thickness | 1/8″ |
| Installed Depth | 0.75″ |
| Length | 4′ |
| Width | 4′ |
| Color | White |
| Country of Origin (COO) | India |
| Display | Backlit Display |
| Display Size | 2″ W x 3″ H (3.5″ Diagonal) |
| Languages | English, French, Spanish |
| Floor Sensor Compatibility | 10k ohms, 12k ohms and custom |
| Included Floor Sensor | 10k ohms, 15' lead |
| Maximum Ambient Temperature Setting | 77 °F |
| Maximum Floor Temperature Setting | 104 °F |
| Minimum Ambient Temperature Setting | 32 °F |
| Minimum Floor Temperature Setting | 41 °F |
| Temperature Rise Limit in Laminate Floor Protection | ~10°F/hr (~5.58°C/hr) |
| Floor Types | Tile, Marble, Stone, Vinyl, LVT, LVP, Wood, Bamboo, Carpet, and more |
| Grate Cover Steel Type | Stainless Steel |
| Shower Pan Density | 3.5 lb/ft³ |
| SKU | SH-272446-ABS-EFH |
| UPC (GTIN-12) | 881308060763 |
