Oval 18ʺ x 26ʺ Mirror Defogger
Part Number: FFM-1826OV
This support page provides publications, manuals, specifications, videos, support articles, and common support questions
This support page provides publications, manuals, specifications, videos, support articles, and common support questions
Common Support Questions (5)
Publications and Manuals (2)
Specifications (20)
Videos (1)
Articles (5)
Similar Items (8)
Create a new Support Request
Shop Now
Common Support Questions
Electric-resistance heating cables and systems have no polarity. This includes all current WarmlyYours heating elements.
Need more help? View support options
The defogging is concentrated in the area of the heating element, but may spread out as the mirror warms up over time. There are too many variable atmospheric conditions that make it impossible to quote a fixed distance of heat spread away from the element. That is why the defogger must be placed in the area of the mirror that requires defogging.
Need more help? View support options
As long as the wood is not glued or attached with any form of mastic to the defogger, yes.
Need more help? View support options
Nothing can be put on the back of the defogger.
Need more help? View support options
Yes.
Need more help? View support options
Publications and Manuals
Specifications
Electrical
| Amps | 0.35 A |
| Ohms | 317 Ω |
| Voltage | 120 V |
| Watts | 38 W |
Warranty / Certifications
| Approvals | cULus listed |
| Proposition 65 Warning | This product contains chemicals including Di-butyl Phthalate (DBP) and Di-2-Ethyl Hexyl Phthalate (DEHP), which are known to the State of California to cause birth defects or other reproductive harm. For more information, visit www.P65Warnings.ca.gov. |
| Warranty | 1-year warranty against defects in materials and workmanship |
Performance
| BTU Per Hour | 130 Btu |
Installation
| Backing | Self-adhesive backing allows direct application to the back of any wall-hung mirror in just minutes |
Logistics
| Country of Origin (COO) | China |
Product Dimensions
| Coverage | 3 ft² |
| Height | 26″ |
| Size (Overall) | 18" x 26" |
| Thickness | 0.5 mm |
| Weight | 0.3 lbs |
| Width | 18″ |
Heat Outputs
| Regulated Heat | 104 F / 40 C |
Identifiers
| SKU | FFM-1826OV |
| UPC (GTIN-12) | 881308010812 |
Appearance
| Shape | Oval |
Videos
Product Line Videos
Articles
Custom Mirror Defogger Design Parameters
Defogger UL Listing
Is the rear surface of the mirror accessible so a defogger can be attached? If so what would be the dimensions of the accessible area?
Length of Mirror Defogger Cold Lead
Mirror Defogger Not Functioning
Defogger UL Listing
Is the rear surface of the mirror accessible so a defogger can be attached? If so what would be the dimensions of the accessible area?
Length of Mirror Defogger Cold Lead
Mirror Defogger Not Functioning
