Plug-in Conversion Kit with GFEP for Self-Regulating Heating Cable (Includes End-Seal Kit)
Ice Shield: Self-Regulating Roof and Gutter Deicing Systems Description
The SR-PLUG-KIT Plug-in Conversion Kit with Ground Fault Equipment Protection (GFEP) for Self-Regulating Heating Cable (part #JSR08) includes materials to facilitate plug-in installation for self-regulating (otherwise hardwired) roof & gutter de-icing or pipe freeze protection systems. This kit provides ground-fault protection and is cULus Listed for 120V (only) ET-SR or PT-SR series cables. An end-termination kit is included. One required for each individual run of cable.
Specifications
Warranty / Certifications
| Approvals | cULus listed |
Logistics
| Country of Origin (COO) | China |
Product Dimensions
| Length | 9ā³ |
| Weight | 0.2 lbs |
| Width | 7ā³ |
Electrical
| Maximum Cable Length | 140ā² |
| Maximum Load (Resistive Only) | 15 A |
| Voltage | 120 V |
Identifiers
| SKU | SR-PLUG-KIT |
| UPC (GTIN-12) | 881308056063 |
Accessories and Spare Parts
Feel free to chat us if you have any questions about these items.
Documents & Manuals
Customer Questions & Answers
Ice Shield: Self-Regulating Roof and Gutter Deicing Systems has 23 Questions and Answers.
Can the heating element be cut to length or shortened?
Our self-regulating heating product is designed to be cut to length at the jobsite by an installer where it can then be end-capped with accessories (sold separately).
However, our constant wattage kits contain heating elements that cannot be shortened or altered in any way.
Do radiant heating products have polarity?
Why a GFEP (GEFP, RCCB, or heat trace circuit breaker) and not a GFCI breaker for WarmlyYours outdoor deicing and snow melting systems?
This National Electric Code (NEC) required protection for fixed outdoor deicing and snow-melting equipment may be accomplished by using circuit breakers equipped with ground-fault equipment protection (GFEP) of 30 mA. It is important to understand that this required equipment protection is not the same as a 5 mA GFCI used for personal protection.
Can the cable be left on in warm weather or all year long?
How do I estimate the roof and gutter deicing cable length needed?
Ā Cable length needed depends on the sizes and areas of the roof that need to be deiced (roof with gutter, downspouts, valleys, and/or dormers). Our best recommendation is for you to give us a call (1-800-875-5285) and we can help you identify what measurements will need to be taken. Alternatively, you can
measure the dimensions of the aforementioned areas and refer to the installation manual to get an idea of how much cable you'll need.Ā
View all 23 Questions and Answers
Customer Reviews
Ice Shield: Self-Regulating Roof and Gutter Deicing Systems achieved an average rating of 5.0 stars with 2 reviews by our customers.
Roof Valley ice buildup
George E., Exmoor, NB on 11/24/2023
After talking with a support person I installed a single run up one valley to the peak and down the other. Weāve only has a couple of snow falls but so far it appears to be doing the job of preventing ice build up. The heat cables are well made and look like they will stand up in a harsh Canadian winter. Finally a system that will work on a steel roof. Friendly and helpful people to deal with. A little pricy but well worth it with the warranty. Satisfied so far.
Roof heat cables, Yes!
Gigi D., La Grange, IL on 02/11/2022
Product works great. WarmlyYours terrific; prepared me with all the necessary information for the installation and back end support if we needed it at the time of installation. Iāll be back.
